Thermoforming Packaging machine
hermoforming packaging machine is used to package a wide range of products in different production sectors such as food, medical materials, consumables, and others. The machine is fed a polyethylene roll to form the cups necessary for packaging through a thermoforming mold, then the product is manually filled in the formed gaps, then it moves to the vacuum stage to draw air and wrap the product with a layer of polyethylene or paper according to the product to be packaged. Finally, the formed and coated roller passes on longitudinal and transverse scissors to separate the products from each other.
|
Technical
Specs
|
|
|
Bottom roll
width
|
360 mm (Customizable)
|
|
Top roll
width
|
330 mm (Customizable)
|
|
Roll outside
diameter
|
Bottom 500
mm, Top 300 mm
|
|
Roll inside diameter
|
76 mm
|
|
Capacity
|
8-10 stroke/min
|
|
Control System
|
Credible international
brand
|
|
Pneumatic
System
|
Credible international
brand
|
|
Sensor
|
Credible international
brand
|
|
Construction
Body
|
Upon Request
|
|
Parts In
Product Contact
|
SS304
|
|
Molds
|
Aluminum 7075
|
|
Compressed Air
Cons.
|
6-8 Bar, (MAX 2000 Liters/min)
|
|
Electricity
Connection
|
Can be produced according to your
country’s connection system.
|
|
Power
Consumption
|
8 KW
|
|
Package Specification
|
PA+PE
|
|
Application
|
This machine can be used to pack food
and medical products like meat, dates, cheese, table olive, etc.
|
