Horizontal Packaging Machine For Liquids
Horizontal packaging machine is fully automatic and prepare 4 side sealed sachet-type packages to fill free flowing granular products that can be packaged trough precise volumetric cups using this model. The sachet size is flexible, both width and height of the sachets can be changed depending on demand this gives the customer a flexible usage
|
Technical
Specs
|
|
|
Number Of Lanes
|
Single Lane
|
|
Filling Weight
Range
|
(1-5 ml) (5-20 ml)
(20-70 ml)
|
|
Bag Width
|
Max 50 mm
|
|
Bag Length
|
Max 150 mm
|
|
Capacity
|
Max 90 pcs/min (Depends
on Product)
|
|
Filling System
|
Servo Motor Driven
Liquid Pump
|
|
Servo Motor
|
Credible international
brand
|
|
Control System
|
Credible international
brand
|
|
Pneumatic
System
|
Credible international
brand
|
|
Sensor
|
Credible international
brand
|
|
Construction
Body
|
Upon Request
|
|
Parts In Product
Contact
|
SS304
|
|
Package Style
Format
|
4
side sealing
|
|
Maximum Roll
Width
|
300 mm Max.
|
|
Maximum Roll
Diameter
|
450 mm Max.
|
|
Compressed Air
Cons.
|
6 Bar, (MAX 450 Liters/min)
|
|
Weight of the
Machine
|
650 Kgs (Approximate)
|
|
Electricity
Connection
|
Can be produced according to your
country’s connection system.
|
|
Power
Consumption
|
10 KW
|
|
Package Specification
|
12 PET, 7 AL, 35-60 PE
|
|
Application
|
Suitable for packing liquid and paste
products, like ketchup, mayonnaise, mustard, honey, and liquid gel cosmetics
such as shampoo, liquid soap etc.
|
|
Optional Features
|
Additional Tank for Fill Powder
Additional Servo Motor
Date Coding System Conveyor Belt -
Easy Open Side Tear Notch Perforation - Gusset
Auto Feeding System – Conveyor Belt
Liquid Pump (Food Graded)
|
