Sachet Packaging Machine For Powders
This fully automatic packaging machine is designed to prepare 4 side sealed sachet-type packages for liquid products can be packaged with these precise pumps. Four side seal sachet packaging machines mainly used in food, cosmetic and pharmaceutical sectors. High weight accuracy, excellent seal integrity to protect filled product.
|
Technical Specs
|
|
|
Number
Of Lanes
|
3-10 Lanes (Depending on Stick Width)
|
|
Filling
Weight Range
|
(2-10 ml) (10-20 ml) (20-50 ml) (50-100 ml)
|
|
Bag
Width
|
Max 150 mm
|
|
Bag
Length
|
40 - 120 mm (adjustable)
|
|
Capacity
|
Max 30 sachets/min/lane (max 500 pcs/min)
|
|
Filling
System
|
Servo Motor Driven
Liquid Pump
|
|
Servo
Motor
|
Credible international
brand
|
|
Control
System
|
Credible international
brand
|
|
Pneumatic
System
|
Credible international
brand
|
|
Sensor
|
Credible international
brand
|
|
Construction
Body
|
Upon Request
|
|
Parts
In Product Contact
|
SS304
|
|
Package
Style Format
|
4 side sealing
|
|
Maximum
Roll Width
|
|
|
Maximum
Roll Diameter
|
450 mm Max.
|
|
Compressed
Air Cons.
|
6 Bar, (MAX 450 Liters/min)
|
|
Weight
of the Machine
|
890 Kgs (Approximate)
|
|
Electricity
Connection
|
Can be produced according to
your country’s connection system.
|
|
Power Consumption
|
10 KW
|
|
Package Specification
|
12 PET, 7 AL, 35-60 PE
|
|
Application
|
Liquid and paste products:
ketchup, mayonnaise, honey, olive oil, vinegar, salad souces, mustard, liquid
cosmetic products, etc.
|
|
Optional Features
|
Date Coding System
Conveyor Belt
Notch For Sachet Machine
Guillotine Notch for Sachet Machine
Perforation
Liquid Pump (Food Graded)
|
