Sachet Packaging Machine
This fully automatic packaging machine that is designed to prepare a 4-side sealed sachet-type packages to fill free flowing granular products. Products that have self-flowability like sugar, salt, black pepper, and other medical grained granules can be packaged through precise volumetric cups using this model.
|
Technical Specs
|
|
|
Number
Of Lanes
|
1-12 Lanes (Depending on Stick Width)
|
|
Filling
Weight Range
|
(3-6 gr Sugar) (0.7-2 gr Salt) (0.25-1 gr
Black Pepper)
|
|
Bag
Width
|
Max 150 mm
|
|
Bag
Length
|
40 - 120 mm (adjustable)
|
|
Capacity
|
Max 30 sachets/min/lane (max 500 pcs/min)
|
|
Filling
System
|
Volumetric Cup Filler
|
|
Servo
Motor
|
Credible international
brand
|
|
Control
System
|
Credible international
brand
|
|
Pneumatic
System
|
Credible international
brand
|
|
Sensor
|
Credible international
brand
|
|
Construction
Body
|
Upon Request
|
|
Parts
In Product Contact
|
SS304
|
|
Package
Style Format
|
4 side sealing
|
|
Maximum
Roll Width
|
|
|
Maximum
Roll Diameter
|
450 mm Max.
|
|
Compressed
Air Cons.
|
6 Bar, (MAX 450 Liters/min)
|
|
Weight
of the Machine
|
750 Kgs (Approximate)
|
|
Electricity
Connection
|
Can be produced according to
your country’s connection system.
|
|
Power Consumption
|
10 KW
|
|
Package
Specification
|
Sugar: 50-60 Paper, 15 PE - Salt: 65 Paper, 12 PE
|
|
Application
|
Free Following Products: sugar,
salt, black pepper etc.
|
|
Optional Features
|
Additional Filling System + Additional
Tank Date Coding System
Conveyor Belt
Easy Open Side Tear Notch Perforation
Auto Feeding System
|
