Stick Packaging Machine for Powders
This fully automatic filling machine is designed to pack untouched. Non free flowing powder products can be packaged with this machine using screws synchronized with PLC in a high level of sensitivity.
|
Technical Specs
|
|
|
Number
Of Lanes
|
3 to 12 Lanes (Depending on Stick Width)
|
|
Filling
Weight Range
|
(0,25-1 gr) (1-5 gr) (5-20 gr) (20-50 gr)
|
|
Bag
Width
|
25 - 65 mm
|
|
Bag
Length
|
170 - 300 mm (adjustable)
|
|
Capacity
|
Max 30
sticks/min/lane (max 500 pcs/min)
|
|
Filling
System
|
Auger Dosing
|
|
Servo
Motor
|
Credible international
brand
|
|
Control
System
|
Credible international
brand
|
|
Pneumatic
System
|
Credible international
brand
|
|
Sensor
|
Credible international
brand
|
|
Construction
Body
|
Upon Request
|
|
Parts
In Product Contact
|
SS304
|
|
Package
Style Format
|
3 side sealing
|
|
Maximum
Roll Width
|
|
|
Maximum
Roll Diameter
|
450 mm Max.
|
|
Compressed
Air Cons.
|
6 Bar, (MAX 450 Liters/min)
|
|
Weight
of the Machine
|
750 Kgs (Approximate)
|
|
Electricity
Connection
|
Can be produced according to
your country’s connection system.
|
|
Power Consumption
|
10 KW
|
|
Package
Specification
|
12 PET, 7 AL, 35-60 PE
|
|
Application
|
Non free flowing products 3 in
1 coffee, coffee cream, powdery chemicals, protein powder; etc.
|
|
Optional Features
|
Additional Filling System + Additional
Tank Date Coding System
Conveyor Belt
Easy Open Side Tear Notch Perforation
Auto Feeding System
|
