Stick Packaging Machine
This machine is designed to fill free flowing products such as sugar, salt, and spices including black pepper through volumetric cups into a three-side sealed stick pack. The volume of the product feed into the volumetric containers can be adjusted between a weight range, this assures that the desired weight is sensitively filled into the stick pack
|
Technical Specs
|
|
|
Number
Of Lanes
|
5-10-12 Lanes (Depending on Stick Width)
|
|
Filling
Weight Range
|
(3-6 gr Sugar) (0.7-2 gr Salt) (0.25-1 gr
Black Pepper)
|
|
Bag
Width
|
17 mm
|
|
Bag
Length
|
170 - 200 mm (adjustable)
|
|
Capacity
|
Max 40 sticks/min/lane (max 500 pcs/min)
|
|
Filling
System
|
Volumetric Cup Filler
|
|
Servo
Motor
|
Credible international
brand
|
|
Control
System
|
Credible international
brand
|
|
Pneumatic
System
|
Credible international
brand
|
|
Sensor
|
Credible international
brand
|
|
Construction
Body
|
Upon Request
|
|
Parts
In Product Contact
|
SS304
|
|
Package
Style Format
|
3 side sealing
|
|
Maximum
Roll Width
|
|
|
Maximum
Roll Diameter
|
450 mm Max.
|
|
Compressed
Air Cons.
|
6 Bar, (MAX 450 Liters/min)
|
|
Weight
of the Machine
|
750 Kgs (Approximate)
|
|
Electricity
Connection
|
Can be produced according to
your country’s connection system.
|
|
Power Consumption
|
10 KW
|
|
Package
Specification
|
12 PET, 7 AL, 35-60 PE
|
|
Application
|
Free Following Products: sugar,
salt, black pepper etc.
|
|
Optional Features
|
Additional Filling System + Additional
Tank Date Coding System
Conveyor Belt
Easy Open Side Tear Notch Perforation
Auto Feeding System
|
