Vertical Packaging Machine - VFFS
The products volumetric weight is calculated by the cups. Each cup provides the same amount of product. The volumetric cups volume can be adjusted from product to product. Thus, customers can pack their products in different weights required. This provides flexibility filling for the customer.
|
Technical
Specs
|
|
|
Number Of Lanes
|
Single Lane
|
|
Filling Weight
Range
|
(20-100 gr) (100-500 gr) (500-2500 gr)
|
|
Bag Width
|
60 - 250 mm (adjustable)
|
|
Bag Length
|
Max 350 mm (adjustable)
|
|
Capacity
|
Max 40 bags/min
|
|
Filling System
|
Volumetric Cup Filler
|
|
Servo Motor
|
Credible international
brand
|
|
Control System
|
Credible international
brand
|
|
Pneumatic
System
|
Credible international
brand
|
|
Sensor
|
Credible international
brand
|
|
Construction
Body
|
Upon Request
|
|
Parts In Product
Contact
|
SS304
|
|
Package Style
Format
|
3 side sealing
|
|
Maximum Roll
Width
|
480 mm Max.
|
|
Maximum Roll
Diameter
|
450 mm Max.
|
|
Compressed Air
Cons.
|
6 Bar, (MAX 450 Liters/min)
|
|
Weight of the
Machine
|
650 Kgs (Approximate)
|
|
Electricity
Connection
|
Can be produced according to your
country’s connection system.
|
|
Power
Consumption
|
10 KW
|
|
Package Specification
|
12 PET, 7 AL, 35-60 PE
|
|
Application
|
Packing rice, sugar, salt, coffee
granules, beans, wheat, grain products, also small granular products such as dried
fruits, nuts etc..
|
|
Optional Features
|
Additional Collar - Date Coding System
Conveyor Belt - Easy Open Side Tear Notch Perforation - Gusset
Auto Feeding System - Elevator
|
